Through snow, sleet, sand or gravel – the OUTLAND OKA’s quick handling and unrivalled versatility makes every ride an adventure. There is no limit to where the OKA can take you.
IMPROVED
500W FAT-BIKE SPECIFIC REAR HUB MOTOR
Powered by our robust 80nm, 500w (750w US Market) brushless geared motor - mountains become mole-hills and thick mud turns to smooth flats. Mated with our innovative iGO Drive Connect App, users can customize rider profiles and style while making the most out of every outing. (Off-Road mode available through dealers where permitted).
EASY AND SAFE TO REMOVE
672WH REMOVABLE BATTERY
Thanks to our fully integrated and removable Lithium-Ion batteries, you’ll be able to ride for hours while retaining the stylish appeal of the bike. Batteries are fully upgradeable and powered by state-of-the-art high capacity cells. Integrated technologies allow for essential stats like range and charge cycles to be monitored.
MORE THAN JUST A SPEEDOMETER AND CALORIE COUNTER
IGO CONNECT
Set your own custom riding profiles (or select from the pre-installed configurations) using the iGO Connect App.
Engage ‘off road mode’ to open up the top speed to 45km/h (where permitted). The iGO Connect App allows for real insight and true customization of your ride.
FRAMESET
FRAME iGO Alloy 6061 Fat 26 ,internal cable routing, in-frame removable battery, Electronics access port
COMPONENTS
HANDLEBAR 700mm Sport
STEM Alloy 2 Degree Rise
SEATPOST Alloy 31.6
SADDLE Velo for iGO
BRAKE LEVERS TEKTRO Auriga Hydraulic
BRAKE CALIPERS TEKTRO Auriga Hydraulic disc
ROTORS 180mm
DRIVETRAIN
SHIFTERS Sram X5, 1x9
FRONT DERAILLEUR na
CHAINRINGS 38T
CHAIN KMC Z8
REAR DERAILLEUR Sram X5, 1x9 speed, Long Cage Black
CASSETTE Sram PG-970 11-34
WHEELS
TIRES Chaoyang 26" x 4”
FORK RST Renegade Air, 120 MM Travel , 26” w/lockout
RIMS iGO Alloy 26x4.0, Black
ELECTRIC TECHNOLOGY
MOTOR Bafang 500 Watt ( 750 Watt Peak ) Geared Rear Hub Drive for Fat Bike
TORQUE up to 80Nm
DISPLAY UNIT iGO TFT Color Backlit, Diagnostic, Battery, Status, BMS Voltage, Light Switch, Main Power, Power-assist Mode Selector, Speedometer, Odometer, Trip Timer
CONTROLLER 48V, High Power Density Sinusodial, Mosfat based up to 70 AMP, Bluetooth
iGo Connect App Available in IOS or Android (April 2020)
BATTERY TYPE SAMSUNG 18650 Removable in Frame Lithium Battery
BATTERY VOLTAGE (V) 48V
BATTERY (AH) 14Ah
BATTERY CAPACITY (WH) 672Wh
RANGE 70km (45mi) *
POWER ASSIST 6 Levels of power assisted pedalling (5 x PAS + 1 x Off Road Mode)
THROTTLE Any time on demand thumb throttle ( Removable )
SENSOR Torque Sensing
CLASS** Class1 / Class3 capable where permitted - max speed 45km/h (28mph)
BATTERY CHARGER 110/220V Smart charger, LED status ,UL, 2A
OTHER
ACCESSORIES (INCLUDED) Rear Cargo Rack Boss for Optional Rack, Water Bottle Boss under Top Tube, Kickstand, Tool Kit
ACCESSORIES (SOLD SEPARATELY) SUNTOUR NEX Suspension Seat Post
